Hub Assembly – Rear
– Big Rig World carries Genuine OEM and Aftermarket parts to repair your vehicle at the lowest prices.
IBS to Outer Surface: Cartridge
Hub Cap Bolt Circle Diameter: 6.375 in.
Outer Cup: BTH-0037; 9904-1074**
Wheel Stud Bolt Circle Diameter: 11.25 in.
Oil Seal: BTH-0037; 9904-1074**
Wheel Stud Hole: .904/.906 in.
Inner Bearing Surface (IBS) to Mounting Face: Cartridge
Inner Cup: BTH-0037; 9904-1074**
Outer Cone: BTH-0037; 9904-1074**
ABS Pilot Diameter: 6.503/6.50 in.
Drum Bolt Size: .904/.906 in.
Drum Bolt Circle Diameter: 11.25 in.
Hub Cap Bolt Thread: 5/16-18 UNC-2B
Inner Cone: BTH-0037; 9904-1074**
Notes: **Cartridge Bearing: BTH-0037 (SKF) ; 9904-1074 (Timken)
Drum Pilot Diameter: 8.778/8.775 in.
Flange Outer Diameter: 13.00 in.
Wheel Pilot Diameter: 8.653/8.646 in.
